hip- Haskell Image Processing (HIP) Library.

Copyright(c) Alexey Kuleshevich 2017
MaintainerAlexey Kuleshevich <lehins@yandex.ru>
Safe HaskellNone






readImage Source #


:: (Array VS cs e, Array arr cs e, Readable (Image VS cs e) InputFormat)
=> FilePath

File path for an image

-> IO (Either String (Image arr cs e))

This function will try to guess an image format from file's extension, then it will attempt to decode it as such. It will fall back onto the rest of the supported formats and will try to read them regarless of file's extension. Whenever image cannot be decoded, Left containing all errors for each attempted format will be returned, and Right containing an image otherwise. Image will be read with a type signature specified:

>>> frog <- readImage "images/frog.jpg" :: IO (Either String (Image VS RGB Word8))
>>> displayImage frog

readImage' :: (Array VS cs e, Array arr cs e, Readable (Image VS cs e) InputFormat) => FilePath -> IO (Image arr cs e) Source #

Just like readImage, but will throw an exception if incorrect format is detected.

readImageExact Source #


:: Readable img format
=> format

A file format that an image should be read as. See Supported Image Formats

-> FilePath

Location of an image.

-> IO (Either String img)

This function allows for reading all supported image in their exact colorspace and precision. Only VS image representation can be read natively, but exchange can be use later to switch to a different representation. For instance, "frog.jpg" image can be read into it's YCbCr colorspace with Word8 precision:

>>> readImageExact JPG "images/frog.jpg" :: IO (Either String (Image VS YCbCr Word8))
Right <Image VS YCbCr (Word8): 200x320>

The drawback here is that colorspace and precision has to match exactly, otherwise it will return an error:

>>> readImageExact JPG "images/frog.jpg" :: IO (Either String (Image VS RGB Word8))
Left "JuicyPixel decoding error: Input image is in YCbCr8 (Pixel YCbCr Word8), cannot convert it to RGB8 (Pixel RGB Word8) colorspace."

Any attempt to read an image in a color space, which is not supported by supplied format, will result in a compile error. Refer to Readable class for all images that can be decoded.

readImageExact' :: Readable b format => format -> FilePath -> IO b Source #

Just like readImageExact, but will throw an exception if incorrect format is detected.


writeImage Source #


:: (Array VS cs e, Array arr cs e, Writable (Image VS cs e) OutputFormat)
=> FilePath

Location where an image should be written.

-> Image arr cs e

An image to write.

-> IO ()

Just like readImage, this function will guess an output file format from the extension and write to file any image that is in one of Y, YA, RGB or RGBA color spaces with Double precision. While doing necessary conversions the choice will be given to the most suited color space supported by the format. For instance, in case of a PNG format, an (Image arr RGBA Double) would be written as RGBA16, hence preserving transparency and using highest supported precision Word16. At the same time, writing that image in GIF format would save it in RGB8, since Word8 is the highest precision GIF supports.

writeImageExact Source #


:: Writable img format
=> format

A file format that an image should be saved in. See Supported Image Formats

-> [SaveOption format]

A list of format specific options.

-> FilePath

Location where an image should be written.

-> img

An image to write. Can be a list of images in case of formats supporting animation.

-> IO ()

Write an image in a specific format, while supplying any format specific options. Precision and color space, that an image will be written as, is decided from image's type. Attempt to write image file in a format that does not support color space and precision combination will result in a compile error.


data ExternalViewer Source #

External viewing application to use for displaying images.


ExternalViewer FilePath [String] Int

Any custom viewer, which can be specified:

  • FilePath - to the actual viewer executable.
  • [String] - command line arguments that will be passed to the executable.
  • Int - position index in the above list where FilePath to an image should be injected

displayImage Source #


:: (Array VS cs e, Array arr cs e, Writable (Image VS cs e) TIF)
=> Image arr cs e

Image to be displayed

-> IO ()

Makes a call to an external viewer that is set as a default image viewer by the OS. This is a non-blocking function call, so it might take some time before an image will appear.

displayImageUsing Source #


:: (Array VS cs e, Array arr cs e, Writable (Image VS cs e) TIF)
=> ExternalViewer

External viewer to use

-> Bool

Should the call be blocking

-> Image arr cs e

Image to display

-> IO ()

An image is written as a .tiff file into an operating system's temporary directory and passed as an argument to the external viewer program.

Common viewers

displayImageFile :: ExternalViewer -> FilePath -> IO () Source #

Displays an image file by calling an external image viewer.

defaultViewer :: ExternalViewer Source #

Default viewer is inferred from the operating system.

gpicviewViewer :: ExternalViewer Source #

gpicview /tmp/hip/img.tiff


fehViewer :: ExternalViewer Source #

feh --fullscreen --auto-zoom /tmp/hip/img.tiff


gimpViewer :: ExternalViewer Source #

gimp /tmp/hip/img.tiff


Supported Image Formats

Encoding and decoding of images is done using JuicyPixels and netpbm packages.

List of image formats that are currently supported, and their exact ColorSpaces and precision for reading and writing without an implicit conversion:

Hands on examples

Animated GIF

JuicyPixels is capable of encoding/decoding all sorts of poular formats, one of which is animated GIFs. Here I would like to present a short demonstration on how it is possible to work with image seqences.

So, we download and image, but it's a little bit too big, and it's in RGBA colorspace.

  • Read an animated GIF as a list of images:
>>> imgs <- readImageExact' GIFA "images/downloaded/strawberry.gif" :: IO [(GifDelay, Image VS RGBA Word8)]
  • convert to RGB colorspace by dropping alpha channel and increasing precision, since we cannot write GIFs in RGBA colorspace:
>>> let imgsRGB = fmap (fmap toImageRGB) imgs
  • if toImageRGB hadn't increased the precision to Double in the previous step, Bilinear interpolation would have simply destroyed the image quality in this step. Scale all images in the sequence by a half:
>>> let imgsRGBsmall = fmap (fmap (scale Bilinear Edge (0.5, 0.5))) imgsRGB
  • Here we save the sequence as a new animated image. We don't need to drop precision back to Word8, it will be taken care for us:
>>> writeImageExact GIFA [GIFALooping LoopingForever] "images/strawberry.gif" imgsRGBsmall
  • Now lets extend the animation a bit:
>>> writeImageExact GIFA [GIFALooping LoopingForever] "images/strawberry_backwards.gif" (imgsRGBsmall ++ reverse imgsRGBsmall)
