Tools for creating symmtery images using the domain coloring algortihm.

- domainColoring :: (RealFloat a, Pixel p, BlackWhite p) => Options a -> Recipe a -> ColorSource a p -> Image p
- blend :: (RealFloat a, Pixel p, BlackWhite p) => Options a -> Recipe a -> Recipe a -> ColorSource a p -> Image p
- morph :: (RealFloat a, Pixel p, BlackWhite p) => Options a -> Recipe a -> a -> ColorSource a p -> Image p
- mkRecipe :: RealFloat a => (Int -> Int -> Recipe a) -> [Coef a] -> Recipe a
- negateCoefs :: Coef a -> Coef a
- negateFst :: Coef a -> Coef a
- negateSnd :: Coef a -> Coef a
- reverseCoefs :: Coef a -> Coef a
- alternateCoefs :: RealFloat a => (Int -> Int -> a) -> Coef a -> Coef a

# Domain Coloring

domainColoring :: (RealFloat a, Pixel p, BlackWhite p) => Options a -> Recipe a -> ColorSource a p -> Image p Source #

blend :: (RealFloat a, Pixel p, BlackWhite p) => Options a -> Recipe a -> Recipe a -> ColorSource a p -> Image p Source #

Make a symmetry image from two `Recipe`

s by linearly interpolation.
The interpolation is along the horizontal axis.

morph :: (RealFloat a, Pixel p, BlackWhite p) => Options a -> Recipe a -> a -> ColorSource a p -> Image p Source #

Make a symmetry image by interpolating between a color wheel and its 180
degree rotation. The cutoff represents what percentage of the
image stays constant at the left and right sides. Like `blend`

the
interpolation is in the horizontal direction.

mkRecipe :: RealFloat a => (Int -> Int -> Recipe a) -> [Coef a] -> Recipe a Source #

Make a recipe from a lattice and a list of Coefficients.

# Coefficients

negateCoefs :: Coef a -> Coef a Source #

Negate the indices of a coefficient.

reverseCoefs :: Coef a -> Coef a Source #

Reverse the indices of a coefficient.

alternateCoefs :: RealFloat a => (Int -> Int -> a) -> Coef a -> Coef a Source #

Multiply a coefficient by a function of its indices, usually used
to change the sign of a coefficient based on its indices.
Does not commute with negate or reverse, usually you want to apply
`alternateCoefs`

first.
