Haskell Image Processing (HIP) library is a wrapper around any array like data structure and is fully agnostic to the underlying representation. All of the functionality in this library relies upon a few type classes, which corresponding representation types are instances of:
- this is a base class for everyArray
arr cs eImage
arr
cs
e
, wherearr
stands for an underlying array representation,cs
is theColorSpace
of an image ande
is the type denoting precision of an image.
- is a kind of array, that can be indexed in constant time and allows monadic operations and mutation on __MArray
arr cs eMImage
st
arr
cs
e
__, which isImage
's mutable cousin.
Array representation type and the above classes it is installed in determine operations that can be done on the image with that representation.
Representations using Vector and Repa packages:
VU
- Unboxed Vector representation. (Default)RS
- Unboxed Repa array representation (computation is done sequentially).RP
- Unboxed Repa array representation (computation is done in parallel).
Images with RS
and RP
types, most of the time hold functions rather then
actual data, this way computation can be fused together, and later changed to
VU
using toManifest
, which in turn performs the fused computation. If at
any time computation needs to be forced, compute
can be used for that
purpose.
Just as it is mentioned above, Vector representation is a default one, so in order to create images with Repa representation Graphics.Image.Interface.Repa module should be used.
Many of the function names exported by this module will clash with the ones from Prelude, hence it can be more convenient to import it qualified and all relevenat types import using Graphics.Image.Types module:
import qualified Graphics.Image as I import Graphics.Image.Types
- makeImage :: Array VU cs Double => (Int, Int) -> ((Int, Int) -> Pixel cs Double) -> Image VU cs Double
- makeImageS :: Array RS cs Double => (Int, Int) -> ((Int, Int) -> Pixel cs Double) -> Image RS cs Double
- makeImageP :: Array RP cs Double => (Int, Int) -> ((Int, Int) -> Pixel cs Double) -> Image RP cs Double
- fromLists :: Array VU cs e => [[Pixel cs e]] -> Image VU cs e
- fromListsS :: Array RS cs e => [[Pixel cs e]] -> Image RS cs e
- fromListsP :: Array RP cs e => [[Pixel cs e]] -> Image RP cs e
- toLists :: MArray arr cs e => Image arr cs e -> [[Pixel cs e]]
- readImageY :: Array arr Y Double => arr -> FilePath -> IO (Image arr Y Double)
- readImageYA :: Array arr YA Double => arr -> FilePath -> IO (Image arr YA Double)
- readImageRGB :: Array arr RGB Double => arr -> FilePath -> IO (Image arr RGB Double)
- readImageRGBA :: Array arr RGBA Double => arr -> FilePath -> IO (Image arr RGBA Double)
- readImageExact :: Readable img format => format -> FilePath -> IO (Either String img)
- writeImage :: Writable (Image arr cs e) OutputFormat => FilePath -> Image arr cs e -> IO ()
- writeImageExact :: Writable img format => format -> [SaveOption format] -> FilePath -> img -> IO ()
- displayImage :: Writable (Image arr cs e) TIF => Image arr cs e -> IO ()
- rows :: BaseArray arr cs e => Image arr cs e -> Int
- cols :: BaseArray arr cs e => Image arr cs e -> Int
- dims :: BaseArray arr cs e => Image arr cs e -> (Int, Int)
- index :: MArray arr cs e => Image arr cs e -> (Int, Int) -> Pixel cs e
- maybeIndex :: MArray arr cs e => Image arr cs e -> (Int, Int) -> Maybe (Pixel cs e)
- defaultIndex :: MArray arr cs e => Pixel cs e -> Image arr cs e -> (Int, Int) -> Pixel cs e
- borderIndex :: MArray arr cs e => Border (Pixel cs e) -> Image arr cs e -> (Int, Int) -> Pixel cs e
- map :: (Array arr cs e, Array arr cs' e') => (Pixel cs' e' -> Pixel cs e) -> Image arr cs' e' -> Image arr cs e
- imap :: (Array arr cs e, Array arr cs' e') => ((Int, Int) -> Pixel cs' e' -> Pixel cs e) -> Image arr cs' e' -> Image arr cs e
- zipWith :: (Array arr cs e, Array arr cs1 e1, Array arr cs2 e2) => (Pixel cs1 e1 -> Pixel cs2 e2 -> Pixel cs e) -> Image arr cs1 e1 -> Image arr cs2 e2 -> Image arr cs e
- izipWith :: (Array arr cs e, Array arr cs1 e1, Array arr cs2 e2) => ((Int, Int) -> Pixel cs1 e1 -> Pixel cs2 e2 -> Pixel cs e) -> Image arr cs1 e1 -> Image arr cs2 e2 -> Image arr cs e
- traverse :: (Array arr cs e, Array arr cs' e') => Image arr cs' e' -> ((Int, Int) -> (Int, Int)) -> (((Int, Int) -> Pixel cs' e') -> (Int, Int) -> Pixel cs e) -> Image arr cs e
- traverse2 :: (Array arr cs e, Array arr cs1 e1, Array arr cs2 e2) => Image arr cs1 e1 -> Image arr cs2 e2 -> ((Int, Int) -> (Int, Int) -> (Int, Int)) -> (((Int, Int) -> Pixel cs1 e1) -> ((Int, Int) -> Pixel cs2 e2) -> (Int, Int) -> Pixel cs e) -> Image arr cs e
- transpose :: Array arr cs e => Image arr cs e -> Image arr cs e
- backpermute :: Array arr cs e => (Int, Int) -> ((Int, Int) -> (Int, Int)) -> Image arr cs e -> Image arr cs e
- (|*|) :: Array arr cs e => Image arr cs e -> Image arr cs e -> Image arr cs e
- fold :: Array arr cs e => (Pixel cs e -> Pixel cs e -> Pixel cs e) -> Pixel cs e -> Image arr cs e -> Pixel cs e
- sum :: Array arr cs e => Image arr cs e -> Pixel cs e
- product :: Array arr cs e => Image arr cs e -> Pixel cs e
- maximum :: (Array arr cs e, Ord (Pixel cs e)) => Image arr cs e -> Pixel cs e
- minimum :: (Array arr cs e, Ord (Pixel cs e)) => Image arr cs e -> Pixel cs e
- normalize :: (Array arr cs e, Array arr Gray e, Fractional e, Ord e) => Image arr cs e -> Image arr cs e
- exchange :: (Exchangable arr' arr, Array arr' cs e, Array arr cs e) => arr -> Image arr' cs e -> Image arr cs e
- data VU = VU
- data RS = RS
- data RP = RP
Color Space
Here is a list of default Pixels with their respective constructors:
*Pixel
Y
e = PixelY y - Luma, also commonly denoted as Y'. *Pixel
YA
e = PixelYA y a - Luma with alpha. *Pixel
RGB
e = PixelRGB r g b - Red, Green and Blue. *Pixel
RGBA
e = PixelRGBA r g b a - RGB with alpha *Pixel
HSI
e = PixelHSI h s i - Hue, Saturation and Intensity. *Pixel
HSIA
e = PixelHSIA h s i a - HSI with alpha *Pixel
CMYK
e = PixelCMYK c m y k - Cyan, Magenta, Yellow and Key (Black). *Pixel
CMYKA
e = PixelCMYKA c m y k a - CMYK with alpha. *Pixel
YCbCr
e = PixelYCbCr y cb cr - Luma, blue-difference and red-difference chromas. *Pixel
YCbCrA
e = PixelYCbCrA y cb cr a - YCbCr with alpha. ------------------------------------------------------------------------------------------ *Pixel
Binary
Bit
=on
|off
- Bi-tonal. *Pixel
cs (Complex
e) = (Pixel
cs e)+:
(Pixel
cs e) - Complex pixels with any color space. *Pixel
Gray
e = PixelGray g - Used for separating channels from other color spaces.
Every Pixel
is an instance of Functor
, Applicative
, Foldable
and
Num
, as well as Floating
and Fractional
if e is also an instance.
All of the functionality related to every ColorSpace
is re-exported by
Graphics.Image.Types module.
Creation
:: Array VU cs Double | |
=> (Int, Int) | ( |
-> ((Int, Int) -> Pixel cs Double) | A function that takes ( |
-> Image VU cs Double |
Create an image with VU
(Vector Unboxed) representation and pixels of Double
precision. Note, that it is essential for Double
precision pixels to keep values
normalized in the [0, 1]
range in order for an image to be written to file
properly.
>>>
let grad_gray = makeImage (200, 200) (\(i, j) -> PixelY (fromIntegral i)/200 * (fromIntegral j)/200)
Because all Pixel
s and Image
s are installed into Num
, above is equivalent to:
>>>
let grad_gray = makeImage (200, 200) (\(i, j) -> PixelY $ fromIntegral (i*j)) / (200*200)
>>>
writeImage "images/grad_gray.png" grad_gray
Creating color images is just as easy.
>>>
let grad_color = makeImage (200, 200) (\(i, j) -> PixelRGB (fromIntegral i) (fromIntegral j) (fromIntegral (i + j))) / 400
>>>
writeImage "images/grad_color.png" grad_color
:: Array RS cs Double | |
=> (Int, Int) | ( |
-> ((Int, Int) -> Pixel cs Double) | A function that takes ( |
-> Image RS cs Double |
Create an image with sequential array representation.
:: Array RP cs Double | |
=> (Int, Int) | ( |
-> ((Int, Int) -> Pixel cs Double) | A function that takes ( |
-> Image RP cs Double |
Create an image with parallel array representation.
fromLists :: Array VU cs e => [[Pixel cs e]] -> Image VU cs e Source #
Construct an image from a nested rectangular shaped list of pixels.
Length of an outer list will constitute m
rows, while the length of inner lists -
n
columns. All of the inner lists must be the same length and greater than 0
.
>>>
fromLists [[PixelY (fromIntegral (i*j) / 60000) | j <- [1..300]] | i <- [1..200]]
<Image VectorUnboxed Y (Double): 200x300>
fromListsS :: Array RS cs e => [[Pixel cs e]] -> Image RS cs e Source #
Construct an image from a nested rectangular shaped list of pixels sequentially.
fromListsP :: Array RP cs e => [[Pixel cs e]] -> Image RP cs e Source #
Construct an image from a nested rectangular shaped list of pixels in parallel.
toLists :: MArray arr cs e => Image arr cs e -> [[Pixel cs e]] Source #
Generates a nested list of pixels from an image.
img == fromLists (toLists img)
IO
Reading
Read supported files into an Image
with pixels in Double
precision. In order to read an image in a different representation, color
space or precision, use readImage
or readImageExact
from
Graphics.Image.IO instead. While reading an
image, it's underlying representation can be specified by passing one of
VU
, RS
or RP
as the first argument to readImage*
functions. Here is
a quick demonstration of how two images can be read as different
representations and later easily combined as their average.
>>>
cluster <- readImageRGB RP "images/cluster.jpg"
>>>
displayImage cluster
>>>
centaurus <- readImageRGB VU "images/centaurus.jpg"
>>>
displayImage centaurus
>>>
displayImage ((cluster + exchange RP centaurus) / 2)
readImageY :: Array arr Y Double => arr -> FilePath -> IO (Image arr Y Double) Source #
Read image as luma (brightness).
readImageYA :: Array arr YA Double => arr -> FilePath -> IO (Image arr YA Double) Source #
Read image as luma with Alpha
channel.
readImageRGB :: Array arr RGB Double => arr -> FilePath -> IO (Image arr RGB Double) Source #
Read image in RGB colorspace.
readImageRGBA :: Array arr RGBA Double => arr -> FilePath -> IO (Image arr RGBA Double) Source #
Read image in RGB colorspace with Alpha
channel.
:: Readable img format | |
=> format | A file format that an image should be read as. See Supported Image Formats |
-> FilePath | Location of an image. |
-> IO (Either String img) |
This function allows for reading any supported image in the exact colorspace
and precision it is currently encoded in. For instance, frog image can be
read into it's YCbCr
colorspace with
Word8
precision and into any supported array
representation.
>>>
readImageExact JPG "images/frog.jpg" :: IO (Either String (Image RP YCbCr Word8))
Right <Image RepaParallel YCbCr (Word8): 200x320>
The drawback here is that colorspace and precision has to match exactly, otherwise it will return an error:
>>>
readImageExact JPG "images/frog.jpg" :: IO (Either String (Image RP RGB Word8))
Left "JuicyPixel decoding error: Input image is in YCbCr8 (Pixel YCbCr Word8), cannot convert it to RGB8 (Pixel RGB Word8) colorspace."
Attempt to read an image in a particular color space that is not supported by
the format, will result in a compile error. Refer to Readable
class for all
images that can be decoded.
Writing
:: Writable (Image arr cs e) OutputFormat | |
=> FilePath | Location where an image should be written. |
-> Image arr cs e | An image to write. |
-> IO () |
Just like readImage
, this function will guess an output file format from the
extension and write to file any image that is in one of Y
, YA
, RGB
or
RGBA
color spaces with Double
precision. While doing necessary
conversions the choice will be given to the most suited color space supported
by the format. For instance, in case of a PNG
format, an (Image
arr
RGBA
Double
) would be written as RGBA16
, hence preserving transparency
and using highest supported precision Word16
. At the same time, writing
that image in GIF
format would save it in RGB8
, since Word8
is the
highest precision GIF
supports and it currently cannot be saved with
transparency.
:: Writable img format | |
=> format | A file format that an image should be saved in. See Supported Image Formats |
-> [SaveOption format] | A list of format specific options. |
-> FilePath | Location where an image should be written. |
-> img | An image to write. Can be a list of images in case of formats supporting animation. |
-> IO () |
Write an image in a specific format, while supplying any format specific options. Precision and color space, that an image will be written as, is decided from image's type. Attempt to write image file in a format that does not support color space and precision combination will result in a compile error.
Makes a call to an external viewer that is set as a default image viewer by the OS. This is a non-blocking function call, so it will take some time before an image will appear.
>>>
frog <- readImageRGB VU "images/frog.jpg"
>>>
displayImage frog
Accessors
Dimensions
rows :: BaseArray arr cs e => Image arr cs e -> Int Source #
Get the number of rows in an image.
>>>
frog <- readImageRGB VU "images/frog.jpg"
>>>
frog
<Image VectorUnboxed RGB (Double): 200x320>>>>
rows frog
200
cols :: BaseArray arr cs e => Image arr cs e -> Int Source #
Get the number of columns in an image.
>>>
frog <- readImageRGB VU "images/frog.jpg"
>>>
frog
<Image VectorUnboxed RGB (Double): 200x320>>>>
cols frog
320
dims :: BaseArray arr cs e => Image arr cs e -> (Int, Int) Source #
Get dimensions of an image.
>>>
frog <- readImageRGB VU "images/frog.jpg"
>>>
frog
<Image VectorUnboxed RGB (Double): 200x320>>>>
dims frog
(200,320)
Indexing
index :: MArray arr cs e => Image arr cs e -> (Int, Int) -> Pixel cs e Source #
Get a pixel at i
-th and j
-th location.
>>>
let grad_gray = makeImage (200, 200) (\(i, j) -> PixelY $ fromIntegral (i*j)) / (200*200)
>>>
index grad_gray (20, 30) == PixelY ((20*30) / (200*200))
True
defaultIndex :: MArray arr cs e => Pixel cs e -> Image arr cs e -> (Int, Int) -> Pixel cs e Source #
Image indexing function that returns a default pixel if index is out of bounds.
borderIndex :: MArray arr cs e => Border (Pixel cs e) -> Image arr cs e -> (Int, Int) -> Pixel cs e Source #
Image indexing function that uses a special border resolutions strategy for out of bounds pixels.
Transformation
Pointwise
map :: (Array arr cs e, Array arr cs' e') => (Pixel cs' e' -> Pixel cs e) -> Image arr cs' e' -> Image arr cs e Source #
Map a function over a an image.
imap :: (Array arr cs e, Array arr cs' e') => ((Int, Int) -> Pixel cs' e' -> Pixel cs e) -> Image arr cs' e' -> Image arr cs e Source #
Map an index aware function over each pixel in an image.
zipWith :: (Array arr cs e, Array arr cs1 e1, Array arr cs2 e2) => (Pixel cs1 e1 -> Pixel cs2 e2 -> Pixel cs e) -> Image arr cs1 e1 -> Image arr cs2 e2 -> Image arr cs e Source #
Zip two images with a function
izipWith :: (Array arr cs e, Array arr cs1 e1, Array arr cs2 e2) => ((Int, Int) -> Pixel cs1 e1 -> Pixel cs2 e2 -> Pixel cs e) -> Image arr cs1 e1 -> Image arr cs2 e2 -> Image arr cs e Source #
Zip two images with an index aware function
Geometric
traverse :: (Array arr cs e, Array arr cs' e') => Image arr cs' e' -> ((Int, Int) -> (Int, Int)) -> (((Int, Int) -> Pixel cs' e') -> (Int, Int) -> Pixel cs e) -> Image arr cs e Source #
Traverse an image
traverse2 :: (Array arr cs e, Array arr cs1 e1, Array arr cs2 e2) => Image arr cs1 e1 -> Image arr cs2 e2 -> ((Int, Int) -> (Int, Int) -> (Int, Int)) -> (((Int, Int) -> Pixel cs1 e1) -> ((Int, Int) -> Pixel cs2 e2) -> (Int, Int) -> Pixel cs e) -> Image arr cs e Source #
Traverse two images.
backpermute :: Array arr cs e => (Int, Int) -> ((Int, Int) -> (Int, Int)) -> Image arr cs e -> Image arr cs e Source #
Backwards permutation of an image.
(|*|) :: Array arr cs e => Image arr cs e -> Image arr cs e -> Image arr cs e Source #
Perform matrix multiplication on two images. Inner dimensions must agree.
Reduction
fold :: Array arr cs e => (Pixel cs e -> Pixel cs e -> Pixel cs e) -> Pixel cs e -> Image arr cs e -> Pixel cs e Source #
Undirected reduction of an image.
maximum :: (Array arr cs e, Ord (Pixel cs e)) => Image arr cs e -> Pixel cs e Source #
Retrieve the biggest pixel from an image
minimum :: (Array arr cs e, Ord (Pixel cs e)) => Image arr cs e -> Pixel cs e Source #
Retrieve the smallest pixel from an image
normalize :: (Array arr cs e, Array arr Gray e, Fractional e, Ord e) => Image arr cs e -> Image arr cs e Source #
Scales all of the pixels to be in the range [0, 1]
.
Representations
exchange :: (Exchangable arr' arr, Array arr' cs e, Array arr cs e) => arr -> Image arr' cs e -> Image arr cs e Source #
Exchange the underlying array representation of an image.
Unboxed Vector
representation.
Show VU Source # | |
Exchangable VU RS Source # | O(1) - Changes to Repa representation. |
Exchangable VU RP Source # | O(1) - Changes to Repa representation. |
Exchangable RS VU Source # | O(1) - Changes to Vector representation. |
Exchangable RP VU Source # | O(1) - Changes to Vector representation. |
Array VU cs e => MArray VU cs e Source # | |
BaseArray VU cs e => Array VU cs e Source # | |
Elt VU cs e => BaseArray VU cs e Source # | |
type Manifest VU Source # | |
data Image VU Source # | |
data MImage st VU Source # | |
type Elt VU cs e Source # | |
Repa U
nboxed Array representation, which is computed sequentially.
Show RS Source # | |
Exchangable VU RS Source # | O(1) - Changes to Repa representation. |
Exchangable RS VU Source # | O(1) - Changes to Vector representation. |
Exchangable RS RP Source # | Changes computation strategy. Will casue all fused operations to be computed. |
Exchangable RP RS Source # | Changes computation strategy. Will casue all fused operations to be computed. |
BaseArray RS cs e => Array RS cs e Source # | |
Elt RS cs e => BaseArray RS cs e Source # | |
type Manifest RS Source # | |
data Image RS Source # | |
type Elt RS cs e Source # | |
Repa U
nboxed Array representation, which is computed in parallel.
Show RP Source # | |
Exchangable VU RP Source # | O(1) - Changes to Repa representation. |
Exchangable RS RP Source # | Changes computation strategy. Will casue all fused operations to be computed. |
Exchangable RP VU Source # | O(1) - Changes to Vector representation. |
Exchangable RP RS Source # | Changes computation strategy. Will casue all fused operations to be computed. |
BaseArray RP cs e => Array RP cs e Source # | |
Elt RP cs e => BaseArray RP cs e Source # | |
type Manifest RP Source # | |
data Image RP Source # | |
type Elt RP cs e Source # | |
