OpenCV.Juicy
Description
A thin JuicyPixels layer.
- type Mat2D h w channels depth = Mat (S '[h, w]) channels depth
- type Filter m h w c d = Mat2D h w c d -> CvExceptT m (Mat2D h w c d)
- type family PixelChannels a :: Nat
- type family PixelDepth a
- fromImage :: forall a c d. (ToDepth (Proxy d), KnownNat c, Pixel a, Storable a, c ~ PixelChannels a, d ~ PixelDepth a) => Image a -> Mat2D D D (S c) (S d)
- toImage :: forall a c d h w. (KnownNat c, Pixel a, Storable a, c ~ PixelChannels a, d ~ PixelDepth a) => Mat2D h w (S c) (S d) -> Image a
- isoJuicy :: forall m. PrimMonad m => (forall c d h w. Filter m h w c d) -> DynamicImage -> CvExceptT m DynamicImage
Types
type Mat2D h w channels depth = Mat (S '[h, w]) channels depth Source #
An OpenCV bidimensional matrix
type Filter m h w c d = Mat2D h w c d -> CvExceptT m (Mat2D h w c d) Source #
An OpenCV 2D-filter preserving the matrix type
type family PixelChannels a :: Nat Source #
map Pixel types to a number of channels
Instances
| type PixelChannels Pixel8 Source # | |
| type PixelChannels Pixel16 Source # | |
| type PixelChannels PixelF Source # | |
| type PixelChannels PixelYA8 Source # | |
| type PixelChannels PixelYA16 Source # | |
| type PixelChannels PixelRGB8 Source # | |
| type PixelChannels PixelRGB16 Source # | |
| type PixelChannels PixelRGBF Source # | |
| type PixelChannels PixelYCbCr8 Source # | |
| type PixelChannels PixelCMYK8 Source # | |
| type PixelChannels PixelCMYK16 Source # | |
| type PixelChannels PixelRGBA8 Source # | |
| type PixelChannels PixelRGBA16 Source # | |
type family PixelDepth a Source #
map Pixel types to a depth
Instances
| type PixelDepth Pixel8 Source # | |
| type PixelDepth Pixel16 Source # | |
| type PixelDepth PixelF Source # | |
| type PixelDepth PixelYA8 Source # | |
| type PixelDepth PixelYA16 Source # | |
| type PixelDepth PixelRGB8 Source # | |
| type PixelDepth PixelRGB16 Source # | |
| type PixelDepth PixelRGBF Source # | |
| type PixelDepth PixelYCbCr8 Source # | |
| type PixelDepth PixelCMYK8 Source # | |
| type PixelDepth PixelCMYK16 Source # | |
| type PixelDepth PixelRGBA8 Source # | |
| type PixelDepth PixelRGBA16 Source # | |
Low level API
Arguments
| :: (ToDepth (Proxy d), KnownNat c, Pixel a, Storable a, c ~ PixelChannels a, d ~ PixelDepth a) | |
| => Image a | JuicyPixels image |
| -> Mat2D D D (S c) (S d) |
Compute an OpenCV 2D-matrix from a JuicyPixels image.
Example:
fromImageImg :: IO (Mat ('S '[ 'D, 'D]) ('S 3) ('S Word8))
fromImageImg = do
r <- Codec.Picture.readImage "data/Lenna.png"
case r of
Left err -> error err
Right (Codec.Picture.ImageRGB8 img) -> pure $ OpenCV.Juicy.fromImage img
Right _ -> error "Unhandled JuicyPixels format!"
Arguments
| :: (KnownNat c, Pixel a, Storable a, c ~ PixelChannels a, d ~ PixelDepth a) | |
| => Mat2D h w (S c) (S d) | OpenCV 2D-matrix |
| -> Image a |
Compute a JuicyPixels image from an OpenCV 2D-matrix
FIXME: There's a bug in the colour conversions in the example:
Example:
toImageImg :: IO (Mat ('S '[ 'D, 'D]) ('S 3) ('S Word8))
toImageImg = exceptError . cvtColor rgb bgr . from . to . exceptError . cvtColor bgr rgb <$> fromImageImg
where
to :: OpenCV.Juicy.Mat2D 'D 'D ('S 3) ('S Word8) -> Codec.Picture.Image Codec.Picture.PixelRGB8
to = OpenCV.Juicy.toImage
from :: Codec.Picture.Image Codec.Picture.PixelRGB8 -> OpenCV.Juicy.Mat2D 'D 'D ('S 3) ('S Word8)
from = OpenCV.Juicy.fromImage
High level API
Arguments
| :: PrimMonad m | |
| => (forall c d h w. Filter m h w c d) | OpenCV 2D-filter |
| -> DynamicImage | JuicyPixels dynamic image |
| -> CvExceptT m DynamicImage |
Apply an OpenCV 2D-filter to a JuicyPixels dynamic matrix, preserving the Juicy pixel encoding
