RigelViz

A (mid-level, simplified, opinionated) Haskell wrapper for vega-lite, currently targeting version 3 of the vega-lite schema.

Aims / definitions

• mid-level :

  • types which can take one of a few possible values are represented by sum types, not by strings.
  • glyph colours are encoded via the colour Haskell library.

• simplified : the generated vega-lite JSON is not normalized, i.e. has some redundancies. This reflects the internal representation but also makes it easier to reason "locally" (i.e. code sections don't visibly exploit inheritance from higher layers).
• opinionated : part of the vega-lite API is not used at all. For example, there is no support for data preprocessing (e.g. summarization etc.). This forces the user to use the host language for preprocessing, which is bound to be more expressive and robust.

Examples

These examples require lucid and lucid-extras (> 0.2.2): lucid provides renderToFile and lucid-extras provides mkVegaHtml.

Scatter plot

render0 :: IO ()
render0 = renderToFile "scatter.html" $ mkVegaHtml $ toJSON vls0

vls0 :: VLSpec TestValue
vls0 =
  vegaLiteSpec 400 300 (DataJSON testVs) [
    layer MCircle (
       posEnc X "tv" Nominal <>
       posEnc Y "tvb" Quantitative <>
       colourEnc "tvb" Quantitative <>
       sizeEnc "tvb" Quantitative
       )
    ]

data TestValue = TV { tv :: T, tvb :: Double } deriving (Eq, Show, Generic)
instance A.ToJSON TestValue
data T = A | B | C deriving (Eq, Show, Generic)
instance A.ToJSON T

testVs :: [TestValue]
testVs = [TV A 3.2, TV B 5.4, TV A 2.2, TV A 6.7, TV B 4.9]

Heatmap

render0 :: IO ()
render0 = renderToFile "heatmap.html" $ mkVegaHtml $ toJSON vls1

vls1 :: VLSpec (V3 Double)
vls1 = vegaLiteSpec 400 400 (DataJSON dats) [
  layer MRect $
      posEnc X "v3x" Ordinal <>
      posEnc Y "v3y" Ordinal  <>
      colourEnc "v3z" Quantitative <>
      sizeEnc "v3z" Quantitative

data V3 a = V3 { v3x :: a, v3y :: a, v3z :: a } deriving (Eq, Show, Generic)
instance A.ToJSON a => A.ToJSON (V3 a)

dats :: [V3 Double]
dats = [V3 x y (f x y) | x <- xs, y <- ys] where
  xs = map (/10) [0, 1 .. 20]
  ys = xs
  f x y = sin $ 2 * pi * sqrt (x ** 2 + y ** 2)

Documentation

vegaLiteSpec

Arguments

:: Int

Plot width

-> Int

Plot height

-> DataSource a

Data source

-> [LayerMetadata]

Plot layer encoding metadata

-> VLSpec a

Create a vega-lite spec

data VLSpec a

Specification of a vega-lite plot

A VLSpec can be encoded into a JSON blob via its ToJSON instance.

Instances

Eq a => Eq (VLSpec a)

Defined in RigelViz

Methods

(==) :: VLSpec a -> VLSpec a -> Bool

(/=) :: VLSpec a -> VLSpec a -> Bool

Show a => Show (VLSpec a)

Defined in RigelViz

Methods

showsPrec :: Int -> VLSpec a -> ShowS

show :: VLSpec a -> String

showList :: [VLSpec a] -> ShowS

Generic (VLSpec a)

Defined in RigelViz

Associated Types

type Rep (VLSpec a) :: Type -> Type

Methods

from :: VLSpec a -> Rep (VLSpec a) x

to :: Rep (VLSpec a) x -> VLSpec a

ToJSON a => ToJSON (VLSpec a)

Defined in RigelViz

Methods

toJSON :: VLSpec a -> Value

toEncoding :: VLSpec a -> Encoding

toJSONList :: [VLSpec a] -> Value

toEncodingList :: [VLSpec a] -> Encoding

type Rep (VLSpec a)

Defined in RigelViz

type Rep (VLSpec a) = D1 (MetaData "VLSpec" "RigelViz" "rigel-viz-0.1.0.0-HOrxoXXdMvrFIi929vBm4i" False) (C1 (MetaCons "VLSpec" PrefixI True) ((S1 (MetaSel (Just "vlsWidth") NoSourceUnpackedness NoSourceStrictness DecidedLazy) (Rec0 Int) :*: S1 (MetaSel (Just "vlsHeight") NoSourceUnpackedness NoSourceStrictness DecidedLazy) (Rec0 Int)) :*: (S1 (MetaSel (Just "vlsData") NoSourceUnpackedness NoSourceStrictness DecidedLazy) (Rec0 (DataSource a)) :*: S1 (MetaSel (Just "vlsView") NoSourceUnpackedness NoSourceStrictness DecidedLazy) (Rec0 [LayerMetadata]))))

Data sources

data DataSource a

Data source

Constructors

DataJSON [a]

Data row type must have a ToJSON instance

DataURI String

URI or filepath of dataset

Instances

Eq a => Eq (DataSource a)

Defined in RigelViz

Methods

(==) :: DataSource a -> DataSource a -> Bool

(/=) :: DataSource a -> DataSource a -> Bool

Show a => Show (DataSource a)

Defined in RigelViz

Methods

showsPrec :: Int -> DataSource a -> ShowS

show :: DataSource a -> String

showList :: [DataSource a] -> ShowS

Generic (DataSource a)

Defined in RigelViz

Associated Types

type Rep (DataSource a) :: Type -> Type

Methods

from :: DataSource a -> Rep (DataSource a) x

to :: Rep (DataSource a) x -> DataSource a

ToJSON a => ToJSON (DataSource a)

Defined in RigelViz

Methods

toJSON :: DataSource a -> Value

toEncoding :: DataSource a -> Encoding

toJSONList :: [DataSource a] -> Value

toEncodingList :: [DataSource a] -> Encoding

type Rep (DataSource a)

Defined in RigelViz

type Rep (DataSource a) = D1 (MetaData "DataSource" "RigelViz" "rigel-viz-0.1.0.0-HOrxoXXdMvrFIi929vBm4i" False) (C1 (MetaCons "DataJSON" PrefixI False) (S1 (MetaSel (Nothing :: Maybe Symbol) NoSourceUnpackedness NoSourceStrictness DecidedLazy) (Rec0 [a])) :+: C1 (MetaCons "DataURI" PrefixI False) (S1 (MetaSel (Nothing :: Maybe Symbol) NoSourceUnpackedness NoSourceStrictness DecidedLazy) (Rec0 String)))

Layer

layer :: MarkType -> EncSet -> LayerMetadata

Declare a plot layer

data LayerMetadata

Layer metadata

Instances

Eq LayerMetadata

Defined in RigelViz

Methods

(==) :: LayerMetadata -> LayerMetadata -> Bool

(/=) :: LayerMetadata -> LayerMetadata -> Bool

Show LayerMetadata

Defined in RigelViz

Methods

showsPrec :: Int -> LayerMetadata -> ShowS

show :: LayerMetadata -> String

showList :: [LayerMetadata] -> ShowS

Generic LayerMetadata

Defined in RigelViz

Associated Types

type Rep LayerMetadata :: Type -> Type

Methods

from :: LayerMetadata -> Rep LayerMetadata x

to :: Rep LayerMetadata x -> LayerMetadata

ToJSON LayerMetadata

Defined in RigelViz

Methods

toJSON :: LayerMetadata -> Value

toEncoding :: LayerMetadata -> Encoding

toJSONList :: [LayerMetadata] -> Value

toEncodingList :: [LayerMetadata] -> Encoding

type Rep LayerMetadata

Defined in RigelViz

type Rep LayerMetadata

Mark

data MarkType

Mark type alternatives

Constructors

MPoint

"point"

MCircle

"circle"

MRect

"rect"

MSquare

"square"

MBar

"bar"

MArea

"area"

MRule

"rule"

MLine

"line"

Instances

Eq MarkType

Defined in RigelViz

Methods

(==) :: MarkType -> MarkType -> Bool

(/=) :: MarkType -> MarkType -> Bool

Show MarkType

Defined in RigelViz

Methods

showsPrec :: Int -> MarkType -> ShowS

show :: MarkType -> String

showList :: [MarkType] -> ShowS

Generic MarkType

Defined in RigelViz

Associated Types

type Rep MarkType :: Type -> Type

Methods

from :: MarkType -> Rep MarkType x

to :: Rep MarkType x -> MarkType

ToJSON MarkType

Defined in RigelViz

Methods

toJSON :: MarkType -> Value

toEncoding :: MarkType -> Encoding

toJSONList :: [MarkType] -> Value

toEncodingList :: [MarkType] -> Encoding

type Rep MarkType

Defined in RigelViz

type Rep MarkType = D1 (MetaData "MarkType" "RigelViz" "rigel-viz-0.1.0.0-HOrxoXXdMvrFIi929vBm4i" False) (((C1 (MetaCons "MPoint" PrefixI False) (U1 :: Type -> Type) :+: C1 (MetaCons "MCircle" PrefixI False) (U1 :: Type -> Type)) :+: (C1 (MetaCons "MRect" PrefixI False) (U1 :: Type -> Type) :+: C1 (MetaCons "MSquare" PrefixI False) (U1 :: Type -> Type))) :+: ((C1 (MetaCons "MBar" PrefixI False) (U1 :: Type -> Type) :+: C1 (MetaCons "MArea" PrefixI False) (U1 :: Type -> Type)) :+: (C1 (MetaCons "MRule" PrefixI False) (U1 :: Type -> Type) :+: C1 (MetaCons "MLine" PrefixI False) (U1 :: Type -> Type))))

Data encoding options

data EncSet

Set of channel encoding options.

Options are created with posEnc, colourEnc, colour, sizeEnc, size and can be added to an EncSet via its Semigroup instance

Instances

Eq EncSet

Defined in RigelViz

Methods

(==) :: EncSet -> EncSet -> Bool

(/=) :: EncSet -> EncSet -> Bool

Show EncSet

Defined in RigelViz

Methods

showsPrec :: Int -> EncSet -> ShowS

show :: EncSet -> String

showList :: [EncSet] -> ShowS

Generic EncSet

Defined in RigelViz

Associated Types

type Rep EncSet :: Type -> Type

Methods

from :: EncSet -> Rep EncSet x

to :: Rep EncSet x -> EncSet

Semigroup EncSet

Defined in RigelViz

Methods

(<>) :: EncSet -> EncSet -> EncSet

sconcat :: NonEmpty EncSet -> EncSet

stimes :: Integral b => b -> EncSet -> EncSet

ToJSON EncSet

Defined in RigelViz

Methods

toJSON :: EncSet -> Value

toEncoding :: EncSet -> Encoding

toJSONList :: [EncSet] -> Value

toEncodingList :: [EncSet] -> Encoding

type Rep EncSet

Defined in RigelViz

type Rep EncSet

posEnc

Arguments

:: Pos

-> Text

Field in the data source

-> EncodingType

-> EncSet

Position encoding

data Pos

Position encoding alternatives

Constructors

X

Y

X2

Y2

Instances

Eq Pos

Defined in RigelViz

Methods

(==) :: Pos -> Pos -> Bool

(/=) :: Pos -> Pos -> Bool

Ord Pos

Defined in RigelViz

Methods

compare :: Pos -> Pos -> Ordering

(<) :: Pos -> Pos -> Bool

(<=) :: Pos -> Pos -> Bool

(>) :: Pos -> Pos -> Bool

(>=) :: Pos -> Pos -> Bool

max :: Pos -> Pos -> Pos

min :: Pos -> Pos -> Pos

Show Pos

Defined in RigelViz

Methods

showsPrec :: Int -> Pos -> ShowS

show :: Pos -> String

showList :: [Pos] -> ShowS

colourEnc

Arguments

:: Text

Field in the data source

-> EncodingType

-> EncSet

Colour encoding

colour :: Colour Double -> EncSet

Fixed colour

size :: Double -> EncSet

Fixed size

sizeEnc

Arguments

:: Text

Field in the data source

-> EncodingType

-> EncSet

Size encoding

data EncodingType

encoding type

Constructors

Nominal

Quantitative

Temporal

Ordinal

Instances

Eq EncodingType

Defined in RigelViz

Methods

(==) :: EncodingType -> EncodingType -> Bool

(/=) :: EncodingType -> EncodingType -> Bool

Ord EncodingType

Defined in RigelViz

Methods

compare :: EncodingType -> EncodingType -> Ordering

(<) :: EncodingType -> EncodingType -> Bool

(<=) :: EncodingType -> EncodingType -> Bool

(>) :: EncodingType -> EncodingType -> Bool

(>=) :: EncodingType -> EncodingType -> Bool

max :: EncodingType -> EncodingType -> EncodingType

min :: EncodingType -> EncodingType -> EncodingType

Show EncodingType

Defined in RigelViz

Methods

showsPrec :: Int -> EncodingType -> ShowS

show :: EncodingType -> String

showList :: [EncodingType] -> ShowS

Generic EncodingType

Defined in RigelViz

Associated Types

type Rep EncodingType :: Type -> Type

Methods

from :: EncodingType -> Rep EncodingType x

to :: Rep EncodingType x -> EncodingType

ToJSON EncodingType

Defined in RigelViz

Methods

toJSON :: EncodingType -> Value

toEncoding :: EncodingType -> Encoding

toJSONList :: [EncodingType] -> Value

toEncodingList :: [EncodingType] -> Encoding

type Rep EncodingType

Defined in RigelViz

type Rep EncodingType = D1 (MetaData "EncodingType" "RigelViz" "rigel-viz-0.1.0.0-HOrxoXXdMvrFIi929vBm4i" False) ((C1 (MetaCons "Nominal" PrefixI False) (U1 :: Type -> Type) :+: C1 (MetaCons "Quantitative" PrefixI False) (U1 :: Type -> Type)) :+: (C1 (MetaCons "Temporal" PrefixI False) (U1 :: Type -> Type) :+: C1 (MetaCons "Ordinal" PrefixI False) (U1 :: Type -> Type)))
